SERIAL HYBRID

DIMENSIONS

LOA: 55' • Beam: 19.5' • Maximum Draft: 3'5"

Air Clearance: 15.4 • Dry Weight: 35,000 lbs • Deck Height: 3'

​

Motors

TOTAL POWER: 110 kW or 200 kW

​

STANDARD MOTOR PACKAGE

Brand: Torqeedo • Model: Deep Blue 55kW

Type: Inboard • Fuel Type: Electric • Power: 80hp

​

UPGRADED MOTOR PACKAGE

Brand: Torqeedo • Model: Deep Blue 100kW

Type: Inboard • Fuel Type: Electric • Power: 160hp

​

FUEL SYSTEM

10 KW SOLAR ARRAY​ • Singlehand • Live Autonomously  Operate with Zero Emissions  • 13+ Knot Top Speed    Operate All Day as Electric • 4+ Hours, 6+ Knots

Specially Equipped for Exploration • Electric with Gusto!

​

ELECTRICAL SYSTEM

170 kWh of Battery Power • Marinized LFP batteries

20kW Fischer Panda Genset • 55/100kW HV Torqeedo Motor    Fully Charge Overnight • Efficient 24v System

110v/220v Appliances • Modular, Future Proof Design

PARALLEL HYBRID

DIMENSIONS

LOA: 55' • Beam: 19.5' • Maximum Draft: 3'5"

Air Clearence: 15.4' • Dry Weight: 36,000 lbs • Deck Height: 3'

​

ENGINES

TOTAL POWER: 520 HP

​​

Motors 2x

Brand: Yanmar • Model: 4LV230

Type: Inboard  • Fuel Type: Diesel Power: 230hp

• Electric Motor: 20kW

​

​​

FUEL SYSTEM

10 KW SOLAR ARRAY​ • Singlehand, Bluewater

Live Autonomously • Operate with Zero Emissions

18+ Knot Continuous Speed • Operate All Day as Electric

 4+ Hours, 6+ Knots  • Specially Equipped for Exploration    Electric with Gusto!

​

ELECTRICAL SYSTEM

60+ kWh of Stored Power • LiFePO4 batteries

15kW Alternator / No Genset • 40kW LV Transfluid Motor

Fully Charge Overnight • Efficient 24v System

110v/220v Appliances • Modular, Future Proof Design
