SERIAL HYBRID
DIMENSIONS
LOA: 55' • Beam: 19.5' • Maximum Draft: 3'5"
Air Clearance: 15.4 • Dry Weight: 35,000 lbs • Deck Height: 3'
​
Motors
TOTAL POWER: 110 kW or 200 kW
​
STANDARD MOTOR PACKAGE
Brand: Torqeedo • Model: Deep Blue 55kW
Type: Inboard • Fuel Type: Electric • Power: 80hp
​
UPGRADED MOTOR PACKAGE
Brand: Torqeedo • Model: Deep Blue 100kW
Type: Inboard • Fuel Type: Electric • Power: 160hp
​
FUEL SYSTEM
10 KW SOLAR ARRAY​ • Singlehand • Live Autonomously Operate with Zero Emissions • 13+ Knot Top Speed Operate All Day as Electric • 4+ Hours, 6+ Knots
Specially Equipped for Exploration • Electric with Gusto!
​
ELECTRICAL SYSTEM
170 kWh of Battery Power • Marinized LFP batteries
20kW Fischer Panda Genset • 55/100kW HV Torqeedo Motor Fully Charge Overnight • Efficient 24v System
110v/220v Appliances • Modular, Future Proof Design
PARALLEL HYBRID
DIMENSIONS
LOA: 55' • Beam: 19.5' • Maximum Draft: 3'5"
Air Clearence: 15.4' • Dry Weight: 36,000 lbs • Deck Height: 3'
​
ENGINES
TOTAL POWER: 520 HP
​​
Motors 2x
Brand: Yanmar • Model: 4LV230
Type: Inboard • Fuel Type: Diesel Power: 230hp
• Electric Motor: 20kW
​
​​
FUEL SYSTEM
10 KW SOLAR ARRAY​ • Singlehand, Bluewater
Live Autonomously • Operate with Zero Emissions
18+ Knot Continuous Speed • Operate All Day as Electric
4+ Hours, 6+ Knots • Specially Equipped for Exploration Electric with Gusto!
​
ELECTRICAL SYSTEM
60+ kWh of Stored Power • LiFePO4 batteries
15kW Alternator / No Genset • 40kW LV Transfluid Motor
Fully Charge Overnight • Efficient 24v System
110v/220v Appliances • Modular, Future Proof Design
