Two tried and tested hybrid models are available,

inquire about the (P) Parallel Hybrid and (S) Serial Hybrid today.

​

The Serial hybrid system is sourced from Torqeedo the leader in electric mobility on the water

with a global service network and more electric motors in the water then any other company.



The Parallel system allows for higher continuous speed while at the same time providing all the benefits of electric

at cruise speed. Plus no generator necessary, saving on maintenance space and weight. The propulsion systems

in each hull can function independently. Providing a redundancy level necessary for blue water and autonomous living.

​

While at rest, the solar array is large enough to generate more power then the hotel uses in a 24 hour cycle.

​

In practical use, you could spend several days at an island then use

the power you stored to travel an additional 10-40 miles to the next island. Leave the diesel

in the tank and travel on green energy.

​

The world is a beautiful place;

Nova Luxe Yachts strives to keep it that way by not polluting.

E44_2023_Renders_6 (1).png

SERIAL HYBRID

DIMENSIONS

LOA: 44' • Beam: 21'9" • Maximum Draft: 2'3"

Air Clearance: 17.4 • Dry Weight: 21,000 lbs • Deck Height: 3'

​

Motors

TOTAL POWER: 110 kW or 220 kW or 440kW

​

STANDARD MOTOR PACKAGE

Brand: Torqeedo • Model: Deep Blue 55kW

Type: Inboard • Fuel Type: Electric • Power: 80hp

​

UPGRADED MOTOR PACKAGE

Brand: Torqeedo • Model: Deep Blue 100kW

Type: Inboard • Fuel Type: Electric • Power: 160hp

Brand: Ingenity • Model: 120kW / 220kW Peak

Type: Inboard • Fuel Type: Electric • Power: 550hp

​

FUEL SYSTEM

7 KW SOLAR ARRAY​ • Singlehand • Live Autonomously  Operate with Zero Emissions  • 13+ Knot Top Speed    Operate All Day as Electric • 4+ Hours, 6+ Knots

Specially Equipped for Exploration • Electric with Gusto!

​

ELECTRICAL SYSTEM

170 kWh of Battery Power • Marinized LFP batteries

20kW Fischer Panda Genset • 55/100kW HV Torqeedo Motor    Fully Charge Overnight • Efficient 24v System

110v/220v Appliances • Modular, Future Proof Design

​

Tankage

Fuel 2 x 240L • Sweetwater 60L • Freshwater 2 x 200L

Greywater 2 x 200L • Blackwater 2 x 100L

PARALLEL HYBRID

DIMENSIONS

LOA: 44' • Beam: 21' 9" • Maximum Draft: 2'3"

Air Clearence: 17.4' • Dry Weight: 22,000 lbs • Deck Height: 3'

​

ENGINES

TOTAL POWER: 360 HP

​

Engine 1

Brand: Yanmar • Model: 4LV150

Type: Inboard  • Fuel Type: Diesel Power: 150hp

• Electric Motor: 20kW

​

Engine 2

Brand: Yanmar • Model: 4LV150

Type: Inboard  • Fuel Type: Diesel Power: 150hp

• Electric Motor: 20kW

​

FUEL SYSTEM

7 KW SOLAR ARRAY​ • Singlehand, Bluewater

Live Autonomously • Operate with Zero Emissions

18+ Knot Continuous Speed • Operate All Day as Electric

 4+ Hours, 6+ Knots  • Specially Equipped for Exploration    Electric with Gusto!

​

ELECTRICAL SYSTEM

60+ kWh of Stored Power • LiFePO4 batteries

15kW Alternator / No Genset • 40kW LV Transfluid Motor

Fully Charge Overnight • Efficient 24v System

110v/220v Appliances • Modular, Future Proof Design
